Price:
3,727.50 ৳
BELDEN 4 PORT CS64AZ-AA PS/2 KVM SWITCH
Key Features
One PS/2 console controls four computers
Compact design, built in 1.8m (6 feet) cables
All-in-one design
With speaker support
Superior video quality- up to 2048 x 1536; DDC2B
Auto Scan function to monitor computer operation
Bus-Powered
Multiplatform support – Windows, Linux
Specification
| Computer Connections | 4 |
| Port Selection | Hotkey |
Connectors | |
| Console Ports | 1 x HDB-15 Female (Blue) 1 x 6-pin Mini-DIN Female (Purple) 1 x 6-pin Mini-DIN Female (Green) 1 x 3.5mm Audio Jack Female (Green) |
| KVM Ports | 4 x HDB-15 Male (Blue) 4 x 6-pin Mini-DIN Male (Purple) 4 x 6-pin Mini-DIN Male (Green) 4 x 3.5mm Audio Jack Male(Green) |
LEDs | |
| Selected | 4 x Green |
Cable Length | |
| Computer | 4 x 1.8 m |
Emulation | |
| Keyboard / Mouse | PS/2 |
| Video | 2048 x 1536; DDC2B |
| Scan Interval | 5 seconds |
| Power Consumption | DC5V:0.41W:6BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded. |
Environmental | |
| Operating Temperature | 0-50°C |
| Storage Temperature | -20-60°C |
| Humidity | 0-80% RH, Non-condensing |
Physical Properties | |
| Housing | Plastic |
| Weight | 0.67 kg ( 1.48 lb ) |
| Dimensions (L x W x H) | 7.86 x 7.86 x 3.06 cm (3.09 x 3.09 x 1.2 in.) |
