Key Features
Print, copy, scan and fax
Up to 24ppm print and copy speed
Up to 2,400 x 600dpi print resolution
Wired network ready + High speed USB 2.0 connection
Up to 35 sheet automatic document feeder
Up to 250 sheet paper capacity
Print Engine | Electrophotographic/Laser |
Processor | ARM9 200MHz |
Warm up Time(From Sleep Mode) | Less than 7 sec. at 73.4F (23℃) |
Warm up Time(From Power ON) | Less than 27 sec. at 73.4F (23℃) |
Standard Capacity | 16 MB |
Paper Input/Standard Tray | 250 sheets |
Paper Input/Manual Feed Slot | 1 sheet |
Paper Input/ADF | 35 sheets |
Paper Output | 100 sheets face-down (80g/m²), 1 sheet face-up (straight paper path) |
LCD Type | 16 characters x 2 lines |
LCD Dimension (W x L) | 1.85 x 0.43 inch |
Laser Notice | Click here for details. |
Media Types/Standard Tray | Plain Paper, Thin Paper, Recycled Paper |
Media Types/Manual Feed Slot | Plain Paper, Thin Paper, Thick Paper, Recycled Paper, Bond Paper, Labels and Envelopes |
Media Types/ADF | Plain Paper, Recycled Paper |
Media Weights/Standard Tray | 60 - 105 g/m² (16 - 28 lb) |
Media Weights/Manual Feed Slot | 60 - 163 g/m² (16 - 43 lb) |
Media Weights/ADF | 64 - 90 g/m² (17 - 24 lb) |
Media Sizes/Standard Tray | A4, Letter, B5(ISO/JIS), A5, A5 (Long Edge), B6(ISO), A6, Executive, Legal, Folio |
Media Sizes/Manual Feed Slot | Width 76.2 to 216 mm, Length 116 to 406.4 mm (Width 3.0" to 8.5", Length 4.6" to 16") |
Media Sizes/ADF | Width 147.3 to 215.9 mm, Length 147.3 to 355.6 mm (Width 5.8" to 8.5", Length 5.8" to 14") |
One-Touch Dial | 8 (4 x 2) locations |
Speed Dial | 200 locations |
Group Dial | Up to 8 groups |
Automatic Redial | Yes |
Modem Speed | 14,400bps (Fax) |
ITU-T Group | G3 |
Document Scanning Width | A4 (ADF): 208 mm, 8.19 inch A4 (FB): 204 mm, 8.03 inch LTR (ADF/FB): 208 mm, 8.19 inch |
Gray Scale | 8 bit / 256 levels |
Memory Transmission | Up to 400 pages (ITU-T Test Chart, Standard Resolution, MMR) |
Broadcasting | 258 locations |
Out-of-Paper Reception | Up to 400 pages (ITU-T Test Chart, Standard Resolution, MMR) |
Resolution | 600 x 600 dpi, HQ1200 (2400 x 600 dpi) quality |
FCOT(From Ready mode and standard tray) | Less than 11 secs |
FCOT(From Sleep mode and standard tray) | Less than 28 secs |
Multi Copy/Stack | Up to 99 |
Multi Copy/Sort | Yes |
Reduction/Enlargement(%) | 25% - 400% in 1% increments |
Document Scanning Width | A4 (ADF/FB): 204 mm, 8.03 inch LTR (ADF/FB): 210 mm, 8.27 inch |
N in 1 | Yes |
Mono/Color | Color |
Resolution From Glass(Optical) | Max 600 x 2400 dpi |
Resolution From ADF(Optical) | Max 600 x 600 dpi |
Gray Scale | 256 levels |
Color Depth (Int. / Ext.) | 48 bit / 24 bit |
USB | Hi-Speed 2.0 |
Printer Driver Windows(Host-Based) | Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Windows Vista®, Windows 7 |
Printer Driver Mac | Mac OS X 10.4.11, 10.5.x, 10.6.x |
Printer Driver Linux | CUPS, LPD/LPRng (x86/x64 environment) |
Scanner Driver Windows | TWAIN, WIA for XP/Windows Vista®/Windows 7 |
Scanner Driver Mac | TWAIN |
Utilities Driver Deployment Wizard | Windows (Host-Based) |
Carton Dimensions (WxDxH) | 527 x 510 x 493 mm (20.8" x 20.1" x 19.4") |
Machine Dimensions (WxDxH) | 405 x 398.5 x 316 mm (15.95" x 15.7" x 12.45") |
Weight w/ Carton | 14.5 kg (32.0 lb) |
Weight w/o Carton, w/ toner/drum | 11.3 kg (24.9 lb) |
Weight w/o Carton and toner/drum | 10.1 kg (22.3 lb) |
Standard Toner | Approx. 1,200 pages in accordance with ISO / IEC 19752 |
High Capacity Toner | Approx. 2,600 pages in accordance with ISO / IEC 19752 |
Drum Unit | Approx. 12,000 pages (1 page / job) |
Power Source | 220-240V AC 50 / 60 Hz |
Power Consumption(Copying) | Average: Approx. 445 W |
Power Consumption(Ready) | Average: Approx. 55 W |
Power Consumption(Deep Sleep) | Average: Approx. 1.5 W |
Sound Pressure Level(Printing) | LpAm = 53 dB(A) |
Sound Pressure Level(Ready) | LpAm = 30 dB(A) |
Sound Power Level(Printing) | LWAd = 6.74 B(A) |
Sound Power Level(Ready) | LWAd = 4.30 B(A) |
