Key Features
MPN: F1504ZA-NJ699
Model: Vivobook 15 F1504ZA
Processor: Intel Core i5-1235U (12M Cache, up to 4.40 GHz)
RAM: 8GB DDR4 , Storage: 512GB Gen4 SSD
Display: 15.6" FHD (1920X1080)
Features: Privacy Shutter, Type-C Port
Processor | |
Processor Brand | Intel |
Processor Model | Core i5-1235U |
Generation | 12 Generation |
Processor Frequency | up to 4.4 GHz |
Processor Core | 10 |
Processor Thread | 12 |
CPU Cache | 12 MB |
Display | |
Display Size | 15.6-inch |
Display Type | LED Backlit |
Display Resolution | FHD (1920 x 1080) |
Touch Screen | No |
Refresh Rate | 60Hz |
Display Features | LED Backlit Anti-glare display TÜV Rheinland-certified Screen-to-Body Ratio: 84% |
Memory | |
RAM | 8GB (Onboard) |
RAM Type | DDR4 |
Removable | Non-Removable |
Bus Speed | 3200MHz |
Total RAM Slot | 1x DDR4 SO-DIMM Slot |
Storage | |
Storage Type | M.2 NVMe PCIe 4.0 SSD |
Storage Capacity | 512GB |
Supported SSD Type | M.2 NVMe PCIe 4.0 SSD |
Graphics | |
Graphics Model | Intel UHD Graphics |
Graphics Memory | Shared |
Graphics Type | Integrated |
Keyboard & TouchPad | |
Keyboard Type | Chiclet Keyboard |
TouchPad | Precision touchpad |
Camera & Audio | |
WebCam | 720p HD camera |
Speaker | Yes |
Microphone | Yes |
Audio Features | SonicMaster with Cortana voice-recognition support |
Ports & Slots | |
HDMI Port | 1x HDMI 1.4 |
USB 2 Port | 1x USB 2.0 Type-A (data speed up to 480Mbps) |
USB 3 Port | 2x USB 3.2 Gen 1 Type-A (data speed up to 5Gbps) |
USB Type-C / Thunderbolt Port | 1x USB 3.2 Gen 1 Type-C (data speed up to 5Gbps) |
Headphone & Microphone Port | 1x 3.5mm Combo Audio Jack |
Network & Connectivity | |
LAN | N/A |
WiFi | Wi-Fi 6E(802.11ax) (Dual band) 1*1 |
Bluetooth | Bluetooth 5.3 |
Security | |
Fingerprint Sensor | N/A |
Camera Privacy Shutter | Yes |
Software | |
Operating System | Free DOS |
Power | |
Battery Type | 3S1P, 3-cell Li-ion |
Battery Capacity | 42WHrs |
Adapter Type | ø4.5, 45W AC Adapter, Output: 19V DC, 2.37A, 45W, Input: 100~240V AC 50/60Hz universal |
Physical Specification | |
Color | Quiet Blue |
Dimensions | 35.97 x 23.25 x 1.79 ~ 1.79 cm |
Weight | With Battery: 1.70 kg (3.75 lbs) Without Battery: 1.50 kg (3.31 lbs) |
Other Features | |
Other Features | System diagnosis Battery health charging Fan Profile Splendid Tru2Life Function key lock WiFi SmartConnect Link to MyASUS TaskFirst Live update AI Noise Canceling |
Warranty | |
Warranty Details | 02 years Warranty (Battery & Adapter 1 Year) |
The ASUS Vivobook 15 F1504ZA is a well-rounded laptop that can suit the needs of students, professionals, and home users alike. Its 12th Generation Intel Core i5-1235U processor provides dependable performance with 10 cores and 12 threads, reaching speeds of up to 4.4 GHz. The 15.6-inch Full HD LED display with anti-glare coating and TÜV Rheinland certification provides bright and comfortable viewing. This Asus laptop has 8GB of DDR4 RAM and a 512GB M.2 NVMe PCIe 4.0 SSD, which provides plenty of memory and fast storage for efficient multitasking and data access. The integrated Intel UHD Graphics handles routine graphics tasks efficiently. A chiclet keyboard, a 720p HD webcam with a privacy shutter, and SonicMaster audio technology improve sound quality.Wi-Fi 6E, Bluetooth 5.3, numerous USB ports, including a USB Type-C port, and an HDMI port provide ample connectivity. The Vivobook 15 also has a Trusted Platform Module (TPM) for security and a 42-watt-hour battery, making it a versatile and trustworthy alternative for varied computing demands.
